High Temperature Resistance Digital Display 4G Wireless Micro Pressure Sensor Gauge Pressure Transmitter

Product Categories
Xi'an Xinyi Instrument Technology Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

High Temperature Resistance Digital Display 4G Wireless Micro Pressure Sensor Gauge Pressure Transmitter

warranty : 2 Years

customized support : OEM, ODM, OBM

place of origin : Shaanxi, China

brand name : XINYI

model number : YW-140

material : High-quality stainless steel

accuracy : High precision

Product name : Gauge Pressure Transmitter

Output : 4-20ma

Pressure type : Gauge Pressure Absolute Pressure Sealed Pressure

Accuracy : 0.5%FS

Supply voltage : DC 24V(12V~32V)

Protection level : IP 65

Usage : Industrial Usage

Pressure range : -0.1....0~0.01... ~100MPa

Application : Wide application range

Quality : High Quality

Price : CN¥2,695.40-3,637.70/pieces

Supply Ability : 3000 Piece/Pieces per Month

Contact Now

Product Description
Pressure Transmitter uses HT series piezoresistive silicon oil-filled sensor as the signal measuring element. Signal processing circuit located in the stainless steel housing, can convert sensor signal into standard output signal. All the products through components and semi-finished products test, finished products burn-in screening, are with stable and reliable performance. Have strong anti-interference performance, can working in harsh environment conditions for long term.
High Temperature Resistance Digital Display 4G Wireless Micro Pressure Sensor Gauge Pressure Transmitter
High Temperature Resistance Digital Display 4G Wireless Micro Pressure Sensor Gauge Pressure Transmitter
High Temperature Resistance Digital Display 4G Wireless Micro Pressure Sensor Gauge Pressure Transmitter
Specification:
Measurement Range
-0.1….0~0.01．．．~100MPa
Proof pressure
≤1.5X rated pressure or 110MPa which ever is less
Pressure type
Gauge, absolute ,sealed gauge
Accuracy
±0.25%（Typical） ±0.5%（Max.）
Long term stability
±0.2%F.S/year
Operating Temperature Range
-20℃~80℃
Storage Temperature Range
-40℃~120℃
Power supply
15～30VDC
Output signal
4～20mA 0～10/20mA 0/1～5VDC
Pressure port
M20×1.5 or customize
material
1Cr18Ni9Ti stainless steel
Diaphragm material
316L
O-ring
Fluororubber
Electrical housing
Cast aluminium alloy(2088housing)
Insulation resistance
100MΩ,100VDC
Protection
IP65
Ordering Note
1. Media must compatible with wetted part. 2. To ensure the products can working reliable, we suggest that customer install lightning protection device and make sure products & power are earthed. 3. Special requirement ,such as strong shock, moment vibration, strong electromagnetism, radio frequency interference ,please consult us. Warranty:Pressure transmitters have a limited one-year warranty to the original purchaser. We will replace or repair defective products free of charge. This warranty does not apply to any units have been modified, misused, neglected.
High Temperature Resistance Digital Display 4G Wireless Micro Pressure Sensor Gauge Pressure Transmitter
Company Profile
High Temperature Resistance Digital Display 4G Wireless Micro Pressure Sensor Gauge Pressure Transmitter
High Temperature Resistance Digital Display 4G Wireless Micro Pressure Sensor Gauge Pressure Transmitter
Certifications
High Temperature Resistance Digital Display 4G Wireless Micro Pressure Sensor Gauge Pressure Transmitter
FAQ
1. WHO ARE WE? We are based in Shaanxi, China, start from 2017,sell to Domestic Market(25.00%),Northern Europe(15.00%),Mid East(15.00%),Africa(10.00%),Southeast Asia(10.00%),North America(5.00%),Eastern Europe(5.00%),Southern Europe(5.00%),Western Europe(5.00%),South America(5.00%). There are total about 11-50 people in our office. 2. HOW CAN WE GUARANTEE QUALITY? Always a pre-production sample before mass production; Always final Inspection before shipment. 3.WHAT CAN YOU BUY FROM US? Pressure transmitter,Digital manometer,Ultrasonic level gauge,Pressure gauge verifier,Input level gauge. 4. WHY SHOULD YOU BUY FROM US NOT FROM OTHER SUPPLIERS? Xinyi technology has a strong r & D team, perfect service system, exquisite sales team. The company has always been adhering to the "price first, quality-oriented, user-oriented" purpose, truly achieve the "quality first, customer first" all the company's. 5. WHAT SERVICES CAN WE PROVIDE? Accepted Delivery Terms: FOB,CIF； Accepted Payment Currency:null; Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash.
